Part Number: XTHA-2FSA

1/4" female NPT x female Quick-test XT, stainless steel

Name: Ralston Instruments
Address: Ralston Instruments P.O. Box 340 Novelty, Ohio 44072 United States, P.O. Box 340 Novelty, Ohio 44072 United States, Ohio, 44072, United States
Telephone: 4405641480
Price range: $

Connect Male NPT pressure gauge or other Male NPT device to a Ralston hand pump or nitrogen calibration device to create one side of a quick-disconnect to 10,000 psi

Request a Quote

To receive pricing, request a quote and a Ralston Distributor will respond.

Get a Quote

Download Datasheet Need help? Contact Us

Specifications

Weight	1.95 oz / 55 grams
Length	1.54 in / 40 mm
Width	0.86 in / 22 mm
Height	0.86 in / 22 mm
Country of origin	USA
Materials	Stainless Steel
Max Operating Temperature	225 °F / 105 °C
Max Pressure	10000 PSI / 700 bar / 70 MPa
Min Operating Temperature	0 °F / -18 °C
Wrench Size	3/4 In / 20 mm
Wrench Size	19 mm / 23/32 in
End 1 Connector	1/4" Female NPT (ASME B1.20.1)
End 1 Direction	Left
End 2 Connector	Female Quick-test XT
End 2 Direction	Left
